POPPET DIRECTIONAL VALVE M-4SED6D1X/350CG96N9K4/V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth M-4SED6D1X/350CG96N9K4/V (R900229218) is a high-performance industrial hydraulic valve designed for precise and reliable switching of oil flow direction. This seat valve is directly actuated and features a spool symbol D, which indicates its specific flow path characteristics. The valve is equipped with an electrical connection that uses a connector pole with PE according to EN standards, ensuring secure and stable connectivity. With the capability to handle a maximum pressure and designed for subplate mounting, this valve conforms to the CE LowVoltage Directive of the EU as well as CSA approval according to CSA C. No. The M-4SED6D1X/350CG96N9K4/V valve operates with a supply voltage of 24 VDC, which powers its solenoid actuation system. It has multiple ports and two switching positions, allowing for versatile application in hydraulic systems. The unit's construction includes concealed manual override and auxiliary actuation features, providing additional control options in various operational scenarios. Connection diagrams are available in both NFPA T3.5.1 R2 D03 Size 6 CETOP and ISO standards for ease of integration into existing systems. This model has been engineered to work with a range of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR types while utilizing FKM seals for enhanced durability against fluid corrosion and temperature variations. The robust design coupled with its versatile capabilities makes the Bosch Rexroth M-4SED6D1X/350CG96N9K4/V an essential component for demanding hydraulic applications requiring precise control over fluid direction and flow rate.
